T-MAX® 3A Timer

Specifications:
Size: Cover Plate: 5.25"H x 5.25"W
PCB: 2.5"H x 3.75"H x 1.5"D
Power: 9-12V (DC or AC), 200ma
Display: 2 digit LED display.
I/O: ADNET: RJ-22 Connections
Power: 2 Screw Terminals*
Contact: 2 Screw Terminals*

Sense: 2 Screw Terminals*
Relay: Switching Capability: 270 VAC @ 5A
Configuration: SPST Form A*(up to 14 AWG)
Mounting: In wall : Fits in standard double-wide plastic switch box.
Exterior
: Optional Metal Enclosure that screws to T-Max® 3A allowing it to be mounted to the wall or placed on a flat surface.



$99.00

_____________________________________________

Includes Everything: 1, 50' tested modular cable with RJ-22 connectors on each end, 1, power supply, and 1, T-Max® 3A User's Guide.

The T-Max® 3A can operate as a stand-alone timer. Up, Down and Start/Stop buttons allow for easy control of your tanning bed. Terminals that screw down provide flexible and easy wire connections. All parameters such as lamp hours, session counts, bed hours etc. can be accessed and changed right on the T-Max® 3A. All of these provide an easy to install and inexpensive way to control a tanning bed from the front desk of your salon.

TwoT-Max® 3As can be connected together for remote, single bed control. Simply place a T-Max® 3A in the tanning room and place the second T-Max® 3A at the front desk and connect them together using the modular cable provided. The T-Max® 3A at the front desk controls the T-Max® 3A in the tanning room. The customer in the tanning room will see their delay time and will be able to press the Start/Stop button to turn the tanning bed on or off, but will not be able to change session times. Session times are controlled by the T-Max® 3A at the front desk.

For larger salons, up to 128 beds can be connected to the T-Max® Manager or T-Max® Manager/Plus in a daisy chain. Simply purchase a T-Max® Manager or T-Max® Manager plus for the front desk and a T-Max® 3A for each tanning bed in the salon. Use the modular cable provided to connect the series from room to room. You can also connect the T-Max® Manager or T-Max® Manager/Plus to a computer and use today’s most popular tanning software to control the beds in your salon.
